RU
Series

SYSTEM 75

Model range (3)

SYSTEM 75 AL

SYSTEM 75 TL

SYSTEM 75 SL

Gallery

Technical specifications

  • Overall base dimensions80,44х92mm
  • Color temperature2700K/3000K/4000K
  • Color Rendering Index (CRI)≥90
  • Power supplyNO DIMM/DALI/BLUETOOTH
  • MODULE LINE
  • Input powerFrom 10,4W/m
  • Luminous fluxFrom 634lm/m
  • MODULE DOT
  • Input power2W
  • Luminous flux200lm
  • Optics45°
  • MODULE UGR
  • Input powerFrom 3,5 W
  • Luminous fluxFrom 278 lm
  • Optics12˚/23˚/38˚/50˚/ 35˚х75˚/50˚х50˚/70˚х70˚
  • MODULE UGR WALLWASH
  • Input powerFrom 3,5 W
  • Luminous fluxFrom 255 lm
  • MODULE AIR ZOOM
  • DimensionsH163 L203 Ø80mm
  • Input power20W
  • Luminous fluxFrom 1325 lm
  • Optics15°- 50°
  • Rotation and tilt angle90°/ 350°
  • MODULE STICK M O/RO
  • DimensionsØ52 L180 H105 mm
  • Input powerFrom 9W
  • Luminous fluxFrom 750 lm
  • Optics O10° / 24° / 36° / 55°
  • Optics RO15° / 30° / 45°
  • Rotation and tilt angle90° / 350°
  • MODULE WALLWASHER
  • DimensionsH232 128х148mm
  • Input power35W
  • Luminous fluxFrom 2966lm
  • Optics30° - 60°
  • Rotation and tilt angle90°/ 350°
