SYSTEM 35

Technical specifications

• Overall base dimensions35х80 mm
• Color temperature2700K/3000K/4000K
• Color Rendering Index (CRI)≥90
• Power supplyNO DIMM/DALI/BLUETOOTH
• Minimum bend radius
• MODULE LINE
• Input powerFrom 10,9 W/m
• Luminous fluxFrom 759 lm/m
• MODULE UGR
• Input powerFrom 3,1 W
• Luminous fluxFrom 218 lm
• Optics15°/24°/38°/50°/35°х70°/40°х40°/60°х60°
• MODULE AIR ZOOM
• Input power20W
• Luminous fluxFrom 1325 lm
• Optics15°-50°
• Rotation and tilt angle90°/ 350°
• MODULE STICK S O/RO
• DimensionsØ52 L50 H105 mm
• Input powerFrom 7 W
• Luminous fluxFrom 600 lm
• Optics O10°/24°/36°/55°
• Optics RO15°/30°/45°
• Rotation and tilt angle90°/ 350°
• MODULE STICK M O/RO
• DimensionsØ52 L180 H105 mm
• Input powerFrom 9 W
• Luminous fluxFrom 750 lm
• Optics O15°/24°/36°/55°
• Optics RO15°/30°/45°
• Rotation and tilt angle90°/ 350°
• MODULE BALL
• DiameterØ100/ 120 / 150 / 175 / 250 mm
• Input power3W
• Luminous flux300lm
• Shade colorGlass/Matte
