SYSTEM 25

Technical specifications

• Overall base dimensions25х46mm
• Color temperature3000K/4000K
• Color Rendering Index (CRI)≥90
• Power supplyNO DIMM/DALI/BLUETOOTH
• MODULE LINE
• Input powerFrom 10,6 W/m
• Luminous fluxFrom 860 lm/m
• MODULE UGR
• Input powerFrom 3,7 W
• Luminous fluxFrom 356 lm
• Optics50°x50°
• MODULE LINE XS
• DimensionsØ38 h65 mm
• Input powerFrom 5W
• Luminous fluxFrom 268lm
• Optics15° / 24° / 36°
• Rotation and tilt angle90°/ 360°
• MODULE BALL
• DiameterØ80/100/120/150/175/250 mm
• Input powerFrom 3W
• Luminous fluxFrom 300lm
• Shade colorGlass/Matte
