SYSTEM 115/80

Technical specifications

• Overall base dimensions80/115 x 80 mm
• Minimum bend radius80mm
• Color temperature3000K/4000K
• Color Rendering Index (CRI)≥90
• Power supplyNO DIMM/DALI/BLUETOOTH
• MODULE LINE
• Input powerFrom 10,9W/m
• Luminous fluxFrom 623lm/m
• MODULE DOT
• Input powerFrom 2W
• Luminous fluxFrom 200 lm
• MODULE KARDAN
• Optics15° / 24° / 36°
• Rotation and tilt angle45°/ 355°
• Input powerFrom 39W
• Luminous fluxFrom 3900lm
• MODULE AIR ZOOM
• Input powerFrom 20W
• Luminous fluxFrom 1325 lm
• Optics15°- 50°
• Rotation and tilt angle90°/ 350°
• MODULE STICK O/RO
• Optics typeLens / Reflector
• Input powerFrom 9W
• Luminous fluxFrom 750 lm
• Optics Lens10° - 55°
• Optics Reflector15° - 45°
• Rotation and tilt angle90° / 350°
• MODULE WALLWASHER
• DimensionsH232 128х148mm
• Input powerFrom 35W
• Luminous fluxFrom 2966lm
• Optics30° - 60°
• Rotation and tilt angle90°/ 350°
